Range from 200CFM to 1400CFM with three different speeds (low, medium, high). 220-240V/1Ph/50Hz power supply is standard; 208-230V/1Ph/60Hz can be customized for floor-standing type. Flexible for installation, designed for horizontal/vertical, concealed/cabinet application. Ultra-thin body, streamlined appearance. Air return from the side or below for increased choice flexibility. 3-way electromagnetic valve can be built inside. Movable louver makes wide angle air flow. Pipe connection from left or right can be selected (in factory).
Range from 200CFM to 1400CFM with three different speeds (low, medium, high).220-240V/1Ph/50Hz power supply is standard; 208-230V/1Ph/60Hz can be customized for floor-standing type. Flexible for installation, designed for horizontal/vertical, concealed/cabinet application. Ultra-thin body, streamlined appearance. Air return from the side or below for increased choice flexibility. 3-way electromagnetic valve can be built inside. Movable louver makes wide angle air flow. Pipe connection from left or right can be selected (in factory
Capacity from Cooling Capacity: 300 to 4000 Ton.Dual Stage and High Efficiency CompressorsFlooded Shell and Tube Evaporator and CondenserAdvance Microprocessor ControllerColour Touch Screen DisplayOptional VFDSuitable for High Ambient and Thermal Energy Storage (TES) ApplicationAHRI CertifiedR134a
American Pro® VRF MRS-X/MRS Series. VRF Outdoor Units (Full DC. Inverter)High efficient DC inverter compressor with energy-saving advantagesEVI Compressor technologyLeading IPLV( C ), up to 5.6180°sine wave DC inverter control Smart control, maximum 1024 indoor unit Unique supercooling control and intercooling circuit designTCC defrost technologyMultiple electronic expansion valve control technologyDual back-up operation function and alternating operation function
The AP.BDQEK series are specially designed and manufactured to makes American Pro® packaged rooftop unit to perform at the highest efficiency possible and operate in a wide ambient temperature range 66°F [18.9°C] to 118°F [48.0°C] it is built specifically for outdoor installation. This series is using R410A refrigerant with cooling capacity range of 9 models from 15.5 to 132 Ton Cooling and 16 to 138 Ton Heating, [56 to 485kW]. with nominal air flow up to 46000 CFM. The units are rated in accordance with AHRI standards 210/240 and 340/360.The AP.BDQEK series with new features is suitable for Hotel, Office, Hospital, School, Factory and Supermarket, villas and more applications. The low noise and compact series are completely leak tested, evacuated, dehydrated and charged with refrigerant prior to shipment (except for unit which evaporator and condenser section is shipped out loosely, refrigerant is charged at field).
